Red Lion 8 Digit, LCD, Counter, 30 V dc

  • RS-stocknr. 905-5649
  • Fabrikantnummer PAXC0030
  • Fabrikant Red Lion
Datasheets
Wetgeving en compliance
N.v.t.
Land van herkomst: US
Productomschrijving

PAX Digital Ratemeter/Counter/Dual Counter

The PAX digital input panel meters are available in 3 different models; PAXC Counter/Dual Counter, PAXR Rate Meter and PAXI which offers both counting and rate. They offer many features and performance capabilities to suit a wide range of industrial applications.

6-digit (14.2 mm) LED display
Red, sunlight readable display
Variable intensity display
3 programmable keys
85-250V ac supply voltage
Four setpoint alarm outputs (with option cards)
Bus capabilities; Devicenet, ModBus and ProfiBus-DP
NEMA 4X/IP65 sealed front bezel


Models:

PAXI (905-5658)- Counter/Dual counter/Rate meter/Slave display
PAXC (905-5630, 905-5649)- Counter/Dual Counter
PAXR (905-5699, 905-5692)- Rate Meter

Red Lion

Specificaties
Kenmerk Waarde
Supply Voltage 11 → 36 V dc, 24 V ac
Display Type LCD
Input Type Logic, Voltage
Connection Type Plug-in Terminal
Reset Method No Reset
Number of Digits 8
Mounting Type DIN
Output / Interface Alarm
Meter Accuracy ±0.01%
Series PAXC
Minimum Measurement -99999999h
Measurement Range ±99999999h
Maximum Operating Temperature +50°C
Cutout Size 1/8 DIN in
Cutout Width 1/8 DINin
Minimum Operating Temperature 0°C
Depth 104.1mm
Function Counter
Meter Type Electronic
Approvals Canadian Requirements Under the Component, Canadian Safety Standards, CSA C22.2, CSA C22.2 No. 14-M95, EN 61010-1, File # E137808, File # E179259, IEC 529, IEC 61010-1, IP20 (Rear of Unit), IP65 (Face Only), LISTED by Und. Lab. Inc. to U.S., No. 61010-1
2 op voorraad - levertijd is 1 werkdag(en).
Prijs Each
285,00
(excl. BTW)
344,85
(incl. BTW)
Aantal stuks
Per stuk
1 - 4
€ 285,00
5 - 9
€ 270,76
10 +
€ 256,51
