Keysight Technologies InfiniiVision 2000 X Series DSOX2012A Oscilloscope, Bench, 2 Channels With UKAS Calibration

Datasheets
Wetgeving en compliance
Vrijgesteld
Land van herkomst: MY
Productomschrijving

Keysight InfiniiVision 2000 X-Series

Keysight InfiniiVision X-Series mixed signal and digital storage oscilloscopes are affordable instruments incorporating advanced technologies which deliver exceptional capabilities. They offer the fastest waveform update rates in their class, for superior viewing of signal detail and capture of infrequent events. Engineers and technicians use oscilloscopes as their primary tools to test and debug designs in the computing, communications, semiconductor, aerospace/defence, automotive and wireless industries. Keysight InfiniiVision X-Series scopes are at work throughout these industries and are credited with being a revolutionary force in engineering education.

Update rates up to 50,000 waveforms/sec
Memory depth 100k points
Input Z 1-MΩ only (no 10:1 auto-detect)
Triggering: Edge; Pulse Width; Pattern; Video
High resolution display intensity gradation

Keysight Technologies Oscilloscopes

The Keysight Technologies 100MHz oscilloscope enables high 200,000 waveforms per second update rate with Keysights 4th generation Mega Zoom technology. It has 2 analogue channels. It has the fastest waveform update rates in its class for superior viewing of signal detail and capture of infrequent events. Engineers and technicians use oscilloscopes as their primary tools to test and debug designs in the computing, communications, semiconductor, aerospace/defence, automotive and wireless industries. Keysight InfiniiVision X-Series scopes are at work throughout these industries and are credited with being a revolutionary force in engineering education.Keysight InfiniiVision 2000 & 3000 X-Series offers the power of 4 instruments in 1: oscilloscope logic analyser
function generator
protocol analyser. The models are fully upgradable (bandwidth, MSO, WaveGen, memory, measurement applications) to meet future requirements and protect the investment.

Features and Benefits

Bandwidth is 100MHz The sample rate is 1GSa/s per channel and 2GSa/s per half-channel Input impedance of 1Mohm Max memory depth of 1Mpts Function Generator is 20MHz Colour display of 8.5in WVGA USB host and device ports for connectivity, memory devices and printing Optional LAN and VGA interface Optional GPIB interface Waveform math and FFT Update rates up to 50,000 waveforms/sec

Certifications

CISPR 11/EN 55011 IEC 61000/EN 61000 compatible Canada: ICES-001:2004 Australia/New Zealand: AS/NZS

Keysight InfiniiVision Series

Keysight InfiniiVision 2000 & 3000 X-Series offers the power of 4 instruments in 1: oscilloscope; logic analyzer; function generator; protocol analyzer. The models are fully upgradable (bandwidth, MSO, WaveGen, memory, measurement applications) to meet future requirements and protect investment.

Specificaties
Kenmerk Waarde
Number of Channels 2
Bandwidth 100MHz
Oscilloscope Type Bench
Series InfiniiVision 2000 X
Calibrated UKAS
Power Source Mains
Display Type Colour
Minimum Vertical Sensitivity 1mV/div
Maximum Vertical Sensitivity 5V/div
Minimum Time Base 5ns/div
Screen Size 8.5in
Sample Rate Random 2 Gsps
Safety Category CAT I 300 V, CAT II 300 V
Model Number p DSOX2012A
Safety Category Voltage 300V
Plug Type Type C - European Plug, Type G - British 3-pin
Safety Category Level CAT I, CAT II
Vertical Resolution 8 bit
5 op voorraad - levertijd is 1 werkdag(en) plus 1 dag extra in verband met gekalibreerd artikel. Gekalibreerde producten kunnen niet worden geretourneerd.
Prijs Each
1.740,00
(excl. BTW)
2.105,40
(incl. BTW)
Aantal stuks
Per stuk
1 +
€ 1.740,00
