PCB Slide Switch Single Pole Double Throw (SPDT) Latching 5 A @ 28 V dc Top

Datasheets
Wetgeving en compliance
Conform
Productomschrijving

RS - Miniature Slide Switches

Suitable for wave soldering at 260ºC for 5 seconds
Black nylon actuator, DAP case and stainless steel housing
Typical applications include PCB or front panel control for hand held products, instrumentation, white goods, medical, IT and telecomms equipment

Specificaties
Kenmerk Waarde
Contact Configuration Single Pole Double Throw (SPDT)
Mounting Type PCB
Switch Operation Latching
Contact Current Rating 5 A @ 28 V dc
Terminal Type Through Hole
Actuator Type Top
Length 12.7mm
Width 6.6mm
Depth 6.35mm
Dimensions 12.7 x 6.6 x 6.35mm
Contact Resistance 10mΩ
Mechanical Life 30000Cycles
Voltage Rating 28V dc
Maximum Operating Temperature +85°C
Minimum Operating Temperature -30°C
Actuator Material Nylon
Operating Temperature Range -30 → +85°C
Contact Material Silver Plated Brass
44 op voorraad - levertijd is 1 werkdag(en) (EU-voorraad)
393 op voorraad - levertijd is 1 werkdag(en) (UK-voorraad)
Prijs Each
2,71
(excl. BTW)
3,28
(incl. BTW)
Aantal stuks
Per stuk
1 - 24
€ 2,71
25 - 99
€ 2,49
100 - 249
€ 1,27
250 - 499
€ 1,06
500 +
€ 0,85
