- RS-stocknr.:
- 170-8062
- Fabrikantnummer:
- BAV99S,135
- Fabrikant:
- Nexperia
tijdelijk niet op voorraad – nieuwe voorraad verwacht op 06-09-2024, met een levertijd van 2 à 3 werkdagen.
Toegevoegd
Prijs Elk (op een haspel van 10000)
€ 0,068
(excl. BTW)
€ 0,082
(incl. BTW)
Aantal stuks | Per stuk | Per reel* |
10000 + | € 0,068 | € 680,00 |
*prijsindicatie |
- RS-stocknr.:
- 170-8062
- Fabrikantnummer:
- BAV99S,135
- Fabrikant:
- Nexperia
Datasheets
Wetgeving en compliance
Productomschrijving
Small Signal Switching Diodes, Nexperia
Features
Supports customised high density circuit designs
Low-leakage and high-voltage types available
High switching speeds
Low capacitance
Low-leakage and high-voltage types available
High switching speeds
Low capacitance
Specificaties
Kenmerk | Waarde |
---|---|
Number of Elements per Chip | 4 |
Mounting Type | Surface Mount |
Package Type | SOT-363 |
Pin Count | 6 |
Maximum Forward Voltage Drop | 1.25V |
Minimum Operating Temperature | -65 °C |
Maximum Operating Temperature | +150 °C |
Length | 2.2mm |
Width | 1.35mm |
Height | 1mm |
Dimensions | 2.2 x 1.35 x 1mm |
Automotive Standard | AEC-Q101 |
Power Dissipation | 250mW |
