STMicroelectronics Through Hole, 3-pin, TRIAC, 600V, Gate Trigger 1.3V 600V
- RS-stocknr.:
- 714-0515
- Fabrikantnummer:
- BTA26-600BRG
- Fabrikant:
- STMicroelectronics
23 op voorraad - levertijd is 1 werkdag(en) (EU-voorraad)
92 op voorraad - levertijd is 3 à 5 werkdagen (UK-voorraad)
Toegevoegd
Prijs Per stuk
€ 5,29
(excl. BTW)
€ 6,40
(incl. BTW)
| Aantal stuks | Per stuk |
| 1 - 4 | € 5,29 |
| 5 - 9 | € 4,96 |
| 10 - 24 | € 4,70 |
| 25 - 49 | € 4,43 |
| 50 + | € 4,22 |
- RS-stocknr.:
- 714-0515
- Fabrikantnummer:
- BTA26-600BRG
- Fabrikant:
- STMicroelectronics
Wetgeving en compliance
Productomschrijving
TRIAC, 25A to 40A, STMicroelectronics
TRIACs, STMicroelectronics
Specificaties
Kenmerk | Waarde |
|---|---|
| Rated Average On-State Current | 25A |
| Mounting Type | Through Hole |
| Package Type | TOP3 |
| Maximum Gate Trigger Current | 100mA |
| Repetitive Peak Reverse Voltage | 600V |
| Surge Current Rating | 260A |
| Pin Count | 3 |
| Maximum Gate Trigger Voltage | 1.3V |
| Repetitive Peak Forward Blocking Voltage | 600V |
| Maximum Holding Current | 80mA |
| Dimensions | 15.5 x 4.6 x 12.85mm |
| Length | 15.5mm |
| Width | 4.6mm |
| Height | 12.85mm |
| Repetitive Peak Off-State Current | 0.005mA |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +125 °C |
| Peak On-State Voltage | 1.55V |
