- RS-stocknr.:
- 123-4821
- Fabrikantnummer:
- 6202-2RSH/C3GJN
- Fabrikant:
- SKF
161 op voorraad - levertijd is 1 werkdag(en).
Toegevoegd
Prijs Per stuk
€ 14,84
(excl. BTW)
€ 17,96
(incl. BTW)
Aantal stuks | Per stuk |
1 - 4 | € 14,84 |
5 - 9 | € 14,23 |
10 - 24 | € 13,93 |
25 + | € 13,65 |
- RS-stocknr.:
- 123-4821
- Fabrikantnummer:
- 6202-2RSH/C3GJN
- Fabrikant:
- SKF
Wetgeving en compliance
- Land van herkomst:
- IT
Productomschrijving
SKF Deep-groove Ball Bearing, Plain Race Type, 15 mm ID - 6202-2RSH/C3GJN
If you need to accommodate radial and axial loads in your machinery, this SKF ball bearing is a simple and reliable solution. It offers a high level of torque with minimal friction, as its deep groove enables the balls to support higher loads. The bearing also helps reduce maintenance costs, as it's pre-lubricated and unlikely to require additional greasing. Its broad operating temperature of -30°C to +150°C makes it suitable for challenging industrial environments.
• Ball made from ceramic material
• Steel cage
• Parallel bore
• Plain race type
• Sealed end
• Single row
• Inside diameter of 15 mm
• Outside diameter of 35 mm
• Race width of 11 mm
• Static load rating of 3.8 kN
• Dynamic load rating of 8.1 kN
• Steel cage
• Parallel bore
• Plain race type
• Sealed end
• Single row
• Inside diameter of 15 mm
• Outside diameter of 35 mm
• Race width of 11 mm
• Static load rating of 3.8 kN
• Dynamic load rating of 8.1 kN
Application Information
• Medical industry
• Construction environments
• Food and beverage industry
• Agriculture
• Construction environments
• Food and beverage industry
• Agriculture
What's the bearing made from?
The internal balls are made from a combination of ceramic and steel, while the cage is made from stainless steel. The steel has an excellent level of strength, and the ceramic can withstand extreme friction and corrosion.
Is the bearing resistant to contaminants?
Yes. To make it reliable, it features metal side shields that prevent liquids, dust and small particles from entering.
Deep Groove Ball Bearings
Specificaties
Kenmerk | Waarde |
---|---|
Inside Diameter | 15mm |
Outside Diameter | 35mm |
Race Width | 11mm |
Ball Bearing Type | Single Row Deep Groove Ball Bearing |
Sealing Arrangement | Both Sides Sealed |
Bearing Clearance | C3 |
Material | Steel |
Ball Material | Steel |
Cage Material | Sheet Metal |
Number of Rows | 1 |
Static Load Rating | 3.75kN |
Dynamic Load Rating | 8.06kN |
Bore Type | Parallel |
Bearing Series | 2 Light |
Partial Bearing Code | 6202 |
Race Type | Plain |
