Europa EUC2P EUC MCB, 2P, 1A Curve C, 230V AC, 10 kA Breaking Capacity
- RS-stocknr.:
- 849-6538
- Fabrikantnummer:
- EUC2P1C
- Fabrikant:
- Europa
Tijdelijk niet op voorraad – nieuwe voorraad verwacht op 23-09-2024, met een levertijd van 1 werkdag.
Prijs Per stuk
€ 17,22
(excl. BTW)
€ 20,84
(incl. BTW)
| Aantal stuks | Per stuk |
| 1 - 9 | € 17,22 |
| 10 - 14 | € 16,52 |
| 15 + | € 15,82 |
- RS-stocknr.:
- 849-6538
- Fabrikantnummer:
- EUC2P1C
- Fabrikant:
- Europa
Datasheets
Wetgeving en compliance
N.v.t.
- Land van herkomst:
- CN
Productomschrijving
Europacomponents MCBs
This range of MCB's are suitable for fitting into consumer units, they have been fully tested and conform to the relevant standards to ensure safety, protection and reliability.
From 6A to 63A
Terminal capacity: 1mm2 to 25mm2
Operating temperature -5° to 40°C
35mm DIN Rail mounting
IP20
Terminal capacity: 1mm2 to 25mm2
Operating temperature -5° to 40°C
35mm DIN Rail mounting
IP20
Standards
IEC 60898, EN 60898
Approvals
CE, SEMKO
Europacomponents Circuit Protection Devices
Specificaties
Kenmerk | Waarde |
|---|---|
| Number of Poles | 2P |
| Current Rating | 1A |
| Tripping Characteristics | Type C |
| Rated AC Voltage | 230 V, 400V |
| Breaking Capacity at Maximum Voltage Rating | 10 kA |
| Range | EUC2P |
| Series | EUC |
| Circuit Breaker Type | MCB |
| Length | 36mm |
| Width | 78mm |
| Mounting Style | DIN Rail Mount |
| Depth | 87mm |
| Model Number | EUC2P1C |
