Festo QSRL Polybutylene Terephthalate Pneumatic Rotary Union, G, Push-in
- RS-stocknr.:
- 202-2817
- Fabrikantnummer:
- QSRL-G1/8-6
- Fabrikant:
- Festo
Subtotaal (1 eenheid)*
€ 21,25
(excl. BTW)
€ 25,71
(incl. BTW)
GRATIS bezorging voor bestellingen van meer dan € 90,00
Op voorraad
- Plus verzending 270 stuk(s) vanaf 12 oktober 2026
- Plus verzending 93 stuk(s) vanaf 12 oktober 2026
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Aantal stuks | Per stuk |
|---|---|
| 1 + | € 21,25 |
*prijsindicatie
- RS-stocknr.:
- 202-2817
- Fabrikantnummer:
- QSRL-G1/8-6
- Fabrikant:
- Festo
Specificaties
Datasheets
Wetgeving en compliance
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | Festo | |
| Product Type | Pneumatic Rotary Union | |
| Connection Thread Size | 1/8 in | |
| Angle | 90° | |
| Sub Type | Rotary Elbow | |
| Connection Thread Standard | G | |
| Series | QSRL | |
| Connection Gender | Male | |
| Material | Polybutylene Terephthalate | |
| Finish | Nickel Plated Brass | |
| Maximum Operating Pressure | 14 bar | |
| Maximum Rotational Speed | 500rpm | |
| Tube Connection Type | Push-in | |
| Tube Connection Size | 6mm | |
| Minimum Operating Temperature | 0°C | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | ISO8573-1:2010 (7:-:-), RoHS | |
| Model Number | 186286 | |
| Alles selecteren | ||
|---|---|---|
Merk Festo | ||
Product Type Pneumatic Rotary Union | ||
Connection Thread Size 1/8 in | ||
Angle 90° | ||
Sub Type Rotary Elbow | ||
Connection Thread Standard G | ||
Series QSRL | ||
Connection Gender Male | ||
Material Polybutylene Terephthalate | ||
Finish Nickel Plated Brass | ||
Maximum Operating Pressure 14 bar | ||
Maximum Rotational Speed 500rpm | ||
Tube Connection Type Push-in | ||
Tube Connection Size 6mm | ||
Minimum Operating Temperature 0°C | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals ISO8573-1:2010 (7:-:-), RoHS | ||
Model Number 186286 | ||
- Land van herkomst:
- JP
Festo Push-In L Fitting, G 1/8, 6mm Tube - QSRL-G1/8-6
This push-in L fitting from Festo is a pneumatic rotary union that joins a static component with a moving one. Use it to join two parts of your high-pressure system and release gas from one to the other through rotation. Its durable construction is designed to be constantly rotated without causing wear to the joint. It has a G 1/8 threaded end that turns securely in place, while its push-in end has a standard 6mm tube size.
• Chemical-resistant PBT (polybutylene terephthalate) housing material
• Low-friction blue POM (polyoxymethylene) release ring prevents heat buildups
• NBR (nitrile rubber) tubing seal with high tensile strength
• Suitable for lubricated operation
• High-alloy steel retaining claw ensures low corrosion stress
Applications
• Factory automation
• Heavy equipment
• Machine tools
• Medical technology
• Oil and gas industry
How does the retaining claw work?
The retaining claw is positioned inside the fitting and absorbs the vibration from constant rotation to prevent surface damage. It also prevents any high-pressure surges from harming the connection's stability. The claw keeps the push-in fitting tightly in place until the release ring is activated.
