Lighting Connectors

For the dependable connection of lighting arrays, lighting connectors are essential. Whether the environment is domestic, commercial or industrial, lighting connectors present the safest and most efficient way to hook up lighting systems to mains power.


No matter how complex your lighting set up, whether LED or halogen, lighting connectors present the most convenient way to get connected.


Lighting Connectors vs. Terminal Blocks


When compared to terminal blocks, the advantages of using lighting connectors are readily apparent. They present a safer, maintenance free alternative to terminal connectors, and also have the advantage of quicker release and connection should you need to reconfigure your lighting array.


Unlike terminal blocks, Lighting Connectors do not have to be screwed and unscrewed when changed, and often present a more secure, definite connection, giving you not just convenience but piece of mind.


While terminal blocks may afford you the option to customise multiple connections into a single block, this is not always desirable as it increases the scope for error and confusion. Bespoke connectors offer a straight forward and purpose-built solution.


Connector Types


The RS Range of lighting connectors offer solutions for many applications. Whether it is screw locking, high IP rated connectors for use in harsh and outdoor environments, or convenient snap-in connectors that eliminate the need for soldering or tedious screwing, there is a lighting connector to suit your needs. The range includes:



  • LED and Halogen connectors

  • Couplers and Adapters

  • In Line Connectors

  • Waterproof Lighting Connectors

  • Wire to Board Connectors


Distribution Units


The range also includes lighting connector distribution units, which are purpose built for linking multiple connectors to a single power connection. Straight forward and easy to use, these distribution units are typically protected against environmental ingress to ensure outdoor suitability.


Strain Relief


Many of the lighting connectors are provided with built in strain relief, meaning the connector prevents the tugging of its internal connection to the wire if pressure is applied. This reduces the need for maintenance and ensures a healthy lifespan for your lighting connection.


...
Lees meer Lees minder

Filters

1 - 20 van 794 producten worden weergegeven
Resultaten per pagina
Omschrijving Prijs Pole Format Series Gender Number of Ways Plug/Socket Colour Type Mounting Type Current Rating Voltage Rating IP Rating Wire Size Cable Length Strain Relief
RS-stocknr. 136-9897
FabrikantRS PRO
€ 10,95
Each
Aantal stuks
2 TeePlug Female 1 Socket Black Tee Socket Cable Mount 10A 400 V IP68 5.8 → 6.9 mm - -
RS-stocknr. 136-3595
FabrikantRS PRO
€ 4,64
Each
Aantal stuks
- - Female, Male - - Black - - - - - - 2.5m -
RS-stocknr. 136-3594
FabrikantRS PRO
€ 4,64
Each
Aantal stuks
- - Female, Male - - Black - - - - - - 5m -
RS-stocknr. 136-9903
FabrikantRS PRO
€ 10,79
Each
Aantal stuks
2 TeePlug Male 1 Plug Black Tee Plug Panel Mount 10A 400 V IP68 - - -
RS-stocknr. 136-9901
FabrikantRS PRO
€ 11,93
Each
Aantal stuks
2 TeePlug Male 1 Plug Black Tee Plug Panel Mount 10A 400 V IP68 - - -
RS-stocknr. 136-9905
FabrikantRS PRO
€ 10,79
Each
Aantal stuks
2 TeePlug Female 1 Socket Black Tee Socket Panel Mount 10A 400 V IP68 - - -
RS-stocknr. 136-9900
FabrikantRS PRO
€ 10,85
Each
Aantal stuks
2 TeePlug Male 1 Plug Black Tee Plug Panel Mount 10A 400 V IP68 - - -
RS-stocknr. 136-9896
FabrikantRS PRO
€ 12,03
Each
Aantal stuks
2 TeePlug Male 1 Plug Black Tee Plug Cable Mount 10A 400 V IP68 7 → 8 mm - -
RS-stocknr. 136-9894
FabrikantRS PRO
€ 10,95
Each
Aantal stuks
2 TeePlug Male 1 Plug Black Tee Plug Cable Mount 10A 400 V IP68 7 → 8 mm - -
RS-stocknr. 136-9904
FabrikantRS PRO
€ 11,87
Each
Aantal stuks
2 TeePlug Male 1 Plug Black Tee Plug Panel Mount 10A 400 V IP68 - - -
RS-stocknr. 136-9898
FabrikantRS PRO
€ 10,95
Each
Aantal stuks
2 TeePlug Female 1 Socket Black Tee Socket Cable Mount 10A 400 V IP68 7 → 8 mm - -
RS-stocknr. 136-9893
FabrikantRS PRO
€ 10,95
Each
Aantal stuks
2 TeePlug Male 1 Plug Black Tee Plug Cable Mount 10A 400 V IP68 5.8 → 6.9 mm - -
RS-stocknr. 136-9895
FabrikantRS PRO
€ 8,16
Each
Aantal stuks
2 TeePlug Male 1 Plug Black Tee Plug Cable Mount 10A 400 V IP68 5.8 → 6.9 mm - -
RS-stocknr. 136-9902
FabrikantRS PRO
€ 10,79
Each
Aantal stuks
2 TeePlug Female 1 Socket Black Tee Socket Panel Mount 10A 400 V IP68 - - -
RS-stocknr. 170-7868
Fabrikantnummer92.931.3053.1
FabrikantWieland
€ 3,312
Each (In a Box of 50)
Aantal stuks
3 GST18i3 Female - Socket Black Mini Connector Cable Mount 20A 250 V IP40 0.75 → 2.5 mm² - Yes
RS-stocknr. 768-4466
Fabrikantnummer92.931.3053.1
FabrikantWieland
€ 4,124
Each (In a Pack of 5)
Aantal stuks
3 GST18i3 Female - Socket Black Mini Connector Cable Mount 20A 250 V IP40 0.75 → 2.5 mm² - Yes
RS-stocknr. 170-7872
Fabrikantnummer92.932.3053.1
FabrikantWieland
€ 2,854
Each (In a Box of 50)
Aantal stuks
3 GST18i3 Male - Plug Black Mini Connector Cable Mount 20A 250 V IP40 0.75 → 2.5 mm² - Yes
RS-stocknr. 768-4478
Fabrikantnummer92.932.3053.1
FabrikantWieland
€ 3,58
Each (In a Pack of 5)
Aantal stuks
3 GST18i3 Male - Plug Black Mini Connector Cable Mount 20A 250 V IP40 0.75 → 2.5 mm² - Yes
RS-stocknr. 342-3226
Fabrikantnummer92.031.3258.1
FabrikantWieland
€ 1,336
Each (In a Pack of 5)
Aantal stuks
3 GST18 Female - Socket Black Connector Cable Mount 16A 250 V IP20 0.5 → 2.5 mm² - -
RS-stocknr. 246-6402
Fabrikantnummer93.016.0053.0
FabrikantWieland
€ 1,536
Each (In a Pack of 5)
Aantal stuks
2 ST16 Male - Plug White Mini Connector Cable Mount 25A 48 V IP20 0.5 → 2.5 mm² - Yes
