Sifam Tinsley Sigma Analogue Panel Ammeter 100 A DC, 68 mm x 68 mm Moving Coil
- RS-stocknr.:
- 886-2001
- Fabrikantnummer:
- PQ74-I20L2N1CAW0ST
- Fabrikant:
- Sifam Tinsley
Bulkkorting beschikbaar
Bekijk bulkkortingSubtotaal (1 eenheid)*
€ 29,46
(excl. BTW)
€ 35,65
(incl. BTW)
GRATIS bezorging voor bestellingen van meer dan € 90,00
Tijdelijk niet op voorraad
- Verzending vanaf 14 december 2026
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Aantal stuks | Per stuk |
|---|---|
| 1 - 4 | € 29,46 |
| 5 - 9 | € 28,57 |
| 10 + | € 27,42 |
*prijsindicatie
- RS-stocknr.:
- 886-2001
- Fabrikantnummer:
- PQ74-I20L2N1CAW0ST
- Fabrikant:
- Sifam Tinsley
Specificaties
Datasheets
Wetgeving en compliance
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | Sifam Tinsley | |
| Product Type | Analogue Panel Ammeter | |
| Current Type | DC | |
| Moving Element | Moving Coil | |
| Cutout Height | 68mm | |
| Cutout Width | 68mm | |
| Depth | 54mm | |
| Maximum Operating Temperature | 55°C | |
| Minimum Operating Temperature | -10°C | |
| Maximum Ampere Value | 100 A | |
| Standards/Approvals | DIN 43802, 93/68/EEC, DIN 40050, VDE 0410, IEC51/DINEN60051, VDE/VDI 3540, 2004/108/EC, DIN 46200/46282, DIN 43701, IEC 61010, 2006/95/EC, IEC 529, IS:1248, DIN 43807, DIN IEC 61554, IEC 1010, VDE 0110, UL 94 V-0 | |
| Maximum Measurement | 1000 V | |
| Series | Sigma | |
| Alles selecteren | ||
|---|---|---|
Merk Sifam Tinsley | ||
Product Type Analogue Panel Ammeter | ||
Current Type DC | ||
Moving Element Moving Coil | ||
Cutout Height 68mm | ||
Cutout Width 68mm | ||
Depth 54mm | ||
Maximum Operating Temperature 55°C | ||
Minimum Operating Temperature -10°C | ||
Maximum Ampere Value 100 A | ||
Standards/Approvals DIN 43802, 93/68/EEC, DIN 40050, VDE 0410, IEC51/DINEN60051, VDE/VDI 3540, 2004/108/EC, DIN 46200/46282, DIN 43701, IEC 61010, 2006/95/EC, IEC 529, IS:1248, DIN 43807, DIN IEC 61554, IEC 1010, VDE 0110, UL 94 V-0 | ||
Maximum Measurement 1000 V | ||
Series Sigma | ||
Niet conform
- Land van herkomst:
- IN
Sigma Series DS Panel Meter
These Sigma Series of DE moving coil panel meters are housed in moulded polycarbonate cases and are suitable for the measurement of DC currents and voltages. The meters offer several advantages in switchboards and Generating Set Panels.
Meters available for mounting in a panel cut out
Available in variety of sizes for both Ammeters & Voltmeters
Linear scale
Glass filled polycarbonate housing
Knife edge pointer
Easily replaceable glass and bezel
Sifam Tinsley Moving Coil Panel Meters
