Productomschrijving

Zoek vergelijkbare producten door een of meer kenmerken te selecteren.

Alles selecteren	Attribuut	Waarde
	Merk	Amphenol India
	Product Type	D-Sub Connector
	Number of Contacts	15
	Orientation	Straight
	Current	7.5A
	Mount Type	Panel
	Connector Gender	Female
	Connector Type D	D-Sub
	Mounting Hardware	Panel
	Housing Material	Glass Filled Polyester
	Voltage	1000 Vrms
	Termination Type	Crimp
	Minimum Operating Temperature	-55°C
	Maximum Operating Temperature	125°C
	Contact Gender	Female
	Standards/Approvals	MIL-DTL-24308, QPL, RoHS, UL 94-0
	Series	M2000
	Contact Material	Copper Alloy
	Contact Plating	Gold Plated
	Pitch	2.77mm

	Alles selecteren
	Merk Amphenol India
	Product Type D-Sub Connector
	Number of Contacts 15
	Orientation Straight
	Current 7.5A
	Mount Type Panel
	Connector Gender Female
	Connector Type D D-Sub
	Mounting Hardware Panel
	Housing Material Glass Filled Polyester
	Voltage 1000 Vrms
	Termination Type Crimp
	Minimum Operating Temperature -55°C
	Maximum Operating Temperature 125°C
	Contact Gender Female
	Standards/Approvals MIL-DTL-24308, QPL, RoHS, UL 94-0
	Series M2000
	Contact Material Copper Alloy
	Contact Plating Gold Plated
	Pitch 2.77mm

Datasheet - M24308/2-286F

Niet conform

Land van herkomst:: IN

The Amphenol M2000 Series D-Sub Connectors are subminiature rack and panel type mounting with polarized shell. It has pin or socket machined contacts which provide high reliability and density for the connectors. They are used in variety of applications due to its versatile design where weight and dimensions are constraint factor.

Used in military, aerospace, industrial, information system, communication system applications

MIL Qualified and listed in QPL

Meets the requirement of MIL-DTL-24308

Amphenol India M2000 15 Way Straight 2.77 mm Pitch Panel D-Sub Connector, with Panel Female
