ABB CRS Series Interface Relay, DIN Rail, 24V dc Coil, SPDT
- RS-stocknr.:
- 231-9464
- Fabrikantnummer:
- 1SVR405501R3010 CR-S024VDC1R
- Fabrikant:
- ABB
Subtotaal (1 eenheid)*
€ 6,62
(excl. BTW)
€ 8,01
(incl. BTW)
GRATIS bezorging voor bestellingen van meer dan € 90,00
Op voorraad
- Plus verzending 52 stuk(s) vanaf 08 juni 2026
- Plus verzending 18 stuk(s) vanaf 08 juni 2026
- Plus verzending 115 stuk(s) vanaf 17 juli 2026
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Aantal stuks | Per stuk |
|---|---|
| 1 + | € 6,62 |
*prijsindicatie
- RS-stocknr.:
- 231-9464
- Fabrikantnummer:
- 1SVR405501R3010 CR-S024VDC1R
- Fabrikant:
- ABB
Specificaties
Datasheets
Wetgeving en compliance
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | ABB | |
| Coil Voltage | 24V dc | |
| Product Type | Interface Relay | |
| Contact Configuration | SPDT | |
| Mount Type | DIN Rail | |
| Series | CRS | |
| Terminal Type | Screw | |
| Switching Current | 6A | |
| Switching DC Voltage | 24V dc | |
| Switching AC Voltage | 250V ac | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Height | 15mm | |
| Standards/Approvals | RoHS | |
| Width | 5mm | |
| Length | 28mm | |
| Alles selecteren | ||
|---|---|---|
Merk ABB | ||
Coil Voltage 24V dc | ||
Product Type Interface Relay | ||
Contact Configuration SPDT | ||
Mount Type DIN Rail | ||
Series CRS | ||
Terminal Type Screw | ||
Switching Current 6A | ||
Switching DC Voltage 24V dc | ||
Switching AC Voltage 250V ac | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
Height 15mm | ||
Standards/Approvals RoHS | ||
Width 5mm | ||
Length 28mm | ||
- Land van herkomst:
- CN
ABB Pluggable Interface Relay, 24V DC Coil Voltage, 6A Load Current Rating - CR-S Series - 1SVR405501R3010 CR-S024VDC1R
Use this interface relay from ABB to transmit signals between field devices and control systems that are isolated from each other. It can also amplify and match operating signals between devices with different electrical potentials. Thanks to its pluggable design, you can easily install it in your automated system, making setup quick. Its compact dimensions of 15 (height) x 28 (depth) x 5mm (width) means it'll fit easily in tight spaces.
Features & Benefits
• Light weight of 0.005kg causes minimal strain on equipment
• Broad operating temperature range of -40°C and +85°C to withstand harsh environments
• Load current rating of 6A for energy efficiency
Applications
• Medical technology
• Automated industrial systems
• Robotics
How does this interface relay work?
When an operating signal is transferred from one component to another, this interface relay adjusts the algorithm to ensure compatibility with the receiving system. The input and output circuits of this relay come with galvanic isolation to prevent signal interference.
How do I mount this interface relay?
You can easily mount this interface relay on a DIN rail, eliminating the need for complex tools.
