Telegartner J60023A0000 Series RJ45 Connector Female, Panel Mount, Cat6a Shielded Straight 1 Port 8 Way
- RS-stocknr.:
- 878-2457
- Fabrikantnummer:
- J60023A0000
- Fabrikant:
- Telegartner
Bulkkorting beschikbaar
Bekijk bulkkortingSubtotaal (1 eenheid)*
€ 178,16
(excl. BTW)
€ 215,57
(incl. BTW)
GRATIS bezorging voor bestellingen van meer dan € 90,00
Op voorraad
- Plus verzending 7 stuk(s) vanaf 07 september 2026
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Aantal stuks | Per stuk |
|---|---|
| 1 - 1 | € 178,16 |
| 2 - 4 | € 164,81 |
| 5 - 9 | € 155,90 |
| 10 + | € 133,62 |
*prijsindicatie
- RS-stocknr.:
- 878-2457
- Fabrikantnummer:
- J60023A0000
- Fabrikant:
- Telegartner
Specificaties
Datasheets
Wetgeving en compliance
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | Telegartner | |
| Product Type | RJ45 Connector | |
| Ethernet Connector Type | RJ45 | |
| LAN Category | Cat6a | |
| Number of Ports | 1 | |
| Mount Type | Panel Mount | |
| Number of Ways | 8 | |
| Connector Gender | Female | |
| Shield Type | Shielded | |
| Orientation | Straight | |
| IP Rating | IP68 | |
| Termination Type | IDC | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Length | 38mm | |
| Standards/Approvals | No | |
| Series | J60023A0000 | |
| Hazardous Area Certification | No | |
| Depth | 81mm | |
| Width | 38mm | |
| Contact Material | Brass Spring Steel | |
| Contact Plating | Nickel | |
| Alles selecteren | ||
|---|---|---|
Merk Telegartner | ||
Product Type RJ45 Connector | ||
Ethernet Connector Type RJ45 | ||
LAN Category Cat6a | ||
Number of Ports 1 | ||
Mount Type Panel Mount | ||
Number of Ways 8 | ||
Connector Gender Female | ||
Shield Type Shielded | ||
Orientation Straight | ||
IP Rating IP68 | ||
Termination Type IDC | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
Length 38mm | ||
Standards/Approvals No | ||
Series J60023A0000 | ||
Hazardous Area Certification No | ||
Depth 81mm | ||
Width 38mm | ||
Contact Material Brass Spring Steel | ||
Contact Plating Nickel | ||
- Land van herkomst:
- DE
Telegärtner DataVoice TOC IP68 Outdoor Cat 6 RJ45 AMJ-S Module T568B Bulkhead Outlet Set
TOC IP68 outdoor cat 6 RJ45 AMJ-S module T568B bulkhead outlet set suitable for use in harsh environment machine and plant engineering applications with a temperature range of -40 to +85°C. Installation requires just one turning movement to lock and seal the connection. This AMJ-S module T568B Cat 6 bulkhead outlet set is suitable for10 Gigabit ethernet transmission acc. to IEEE 802.3an and PoE+ acc. to IEEE 802.3at and has a nickel plated brass bulkhead outlet housing, a white PC UL94 V0 insulation body and 360° shielding. An IP68 bulkhead protective cap (stock number 878-2494) and a 38mm & TH35 bracket (stock number 878-2450) are available separately
Telegärtner DataVoice TOC IP68 Outdoor RJ45 Couplers, Plug Sets and Bulkhead Sets
Standards
Connector standard to IEC 60603-7-51
Category 6A: ANSI/TIA/EIA-568-C.2
Category 6: ISO/IEC 11801, EN 50173-1
IP68 protection to IEC 60529
Category 6A: ANSI/TIA/EIA-568-C.2
Category 6: ISO/IEC 11801, EN 50173-1
IP68 protection to IEC 60529
