Norgren B07 Filter Regulator, 40 μm, 1/8 in, Manual, 10 bar

RS-stocknr.:: 122-683
Fabrikantnummer:: B07-101-M3KG
Fabrikant:: Norgren

Norgren B07 Filter Regulator, 40 μm, 1/8 in, Manual, 10 bar

Bulkkorting beschikbaar

Bekijk bulkkorting

Subtotaal (1 eenheid)*

€ 73,22

(excl. BTW)

€ 88,60

(incl. BTW)

GRATIS bezorging voor bestellingen van meer dan € 90,00

Op voorraad

Plus verzending 2 stuk(s) vanaf 01 juni 2026
Plus verzending 13 stuk(s) vanaf 01 juni 2026

Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.

Aantal stuks	Per stuk
1 - 4	€ 73,22
5 +	€ 70,98

*prijsindicatie

RS-stocknr.:: 122-683
Fabrikantnummer:: B07-101-M3KG
Fabrikant:: Norgren

Specificaties

Datasheets

Wetgeving en compliance

Productomschrijving

Zoek vergelijkbare producten door een of meer kenmerken te selecteren.

Alles selecteren	Attribuut	Waarde
	Merk	Norgren
	Port Size	1/8 in
	Product Type	Filter Regulator
	Maximum Flow Rate	6.2dm³/s
	Maximum Operating Pressure	10 bar
	Series	B07
	Connection Thread Standard	G
	Drain Type	Manual
	Filtration Size	40μm
	Pressure Gauge Port Size	1/8 in
	Overall Length	28mm
	Minimum Operating Temperature	-34°C
	Maximum Operating Temperature	50°C
	Overall Width	41mm
	Standards/Approvals	RoHS
	Overall Height	210mm
	Pressure Setting Range	0.3 to 7 bar
	Pressure Gauge Port Thread Standard	Rc
	Bowl Material	Polycarbonate

	Alles selecteren
	Merk Norgren
	Port Size 1/8 in
	Product Type Filter Regulator
	Maximum Flow Rate 6.2dm³/s
	Maximum Operating Pressure 10 bar
	Series B07
	Connection Thread Standard G
	Drain Type Manual
	Filtration Size 40μm
	Pressure Gauge Port Size 1/8 in
	Overall Length 28mm
	Minimum Operating Temperature -34°C
	Maximum Operating Temperature 50°C
	Overall Width 41mm
	Standards/Approvals RoHS
	Overall Height 210mm
	Pressure Setting Range 0.3 to 7 bar
	Pressure Gauge Port Thread Standard Rc
	Bowl Material Polycarbonate

Norgren B07 40μm G 1/8 FR Assembly

Vrijgesteld

Land van herkomst:: MX

IMI Norgren Manual Drain Filter Regulator, 0.3 to 10 Bar, 40μm Filtration Size - B07 Series - B07-101-M3KG

Keep compressed air free of dirt and moisture with this filter regulator from IMI Norgren. The unit features a filter to clean air, as well as a regulator to ensure that downstream pneumatic equipment is supplied with constant air pressure. This reduces the risk of damage to components and increases the longevity and efficiency of your pneumatic circuit. The unit's screw-in filter bowl is simple to remove and clean, saving you time and effort during maintenance. For added safety, a snap-action knob locks securely once the pressure has been set to prevent accidental changes to your pressure settings.

Features & Benefits

• Durable sintered plastic filter element for resistance to wear and impact

• Zinc alloy body material is corrosion-resistant and durable

• Wide operating temperature range of -34°C to +50°C for use in demanding conditions

Applications

• Food and drink production

• Heating and cooling equipment

• Compressors

How do you know when the filter bowl on this unit needs to be cleaned?

This unit's polycarbonate (PC) filter bowl is transparent, so a quick visual inspection will let you know when to clean it.
