RS PRO C550S Series 9-Contact Female Interface Module, RJ45 Connector, DIN Rail, 1A

Bekijk alle Interface Modules

Subtotaal (1 doos van 1 eenheid)*

€ 16,06

(excl. BTW)

€ 19,43

(incl. BTW)

Add to Basket
selecteer of typ hoeveelheid
Op voorraad
  • 20 stuk(s) klaar voor verzending vanaf een andere locatie
  • Plus verzending 235 stuk(s) vanaf 26 maart 2026
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Dozen
Per Doos
1 +€ 16,06

*prijsindicatie

RS-stocknr.:
265-7028
Artikelnummer Distrelec:
304-19-238
Fabrikant:
RS PRO
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren

Merk

RS PRO

Gender

Female

Product Type

Interface Module

Wire Size

24/12 AWG

Current

1A

Number of Contacts

9

Orientation

Straight

Connector Type

RJ45

Mount Type

DIN Rail

Voltage

48 V dc

Cable CSA

0.14 to 2.5 mm²

Depth

32mm

Width

35.2 mm

Standards/Approvals

RS Professionally Approved Products

Length

77.9mm

Series

C550S

Land van herkomst:
CN

RS PRO RJ45 Interface Module for 35mm DIN Rail, 48V, 1A


A 35mm DIN rail mount interface module featuring an RJ45 connector for the integration of electronic devices and components to industrial and electrical systems.;Built from robust plastic the RJ45 interface module consists of a straight RJ45 port for network or ethernet connection and 2 rows of M2.5 screw down terminals angled at 45° for unrestricted access and easy wire termination.;The 2 terminal blocks contain 4 and 5 contacts for a total of 9 contacts suitable for wire sizes 24 to 12AWG (0.14 – 2.5mm) with simple screw down termination. An easy to install and wire interface module suitable for use in a wide range of automation and control applications.

Features and Benefits


RJ45 interface module

35mm DIN rail mount

Voltage rating of 48Vdc

Current rating of 1A

1 x RJ45 port

9 x M.25 screw terminals

45° terminals for easy access.

Suitable for wire sizes 0.14 to 2.5 mm² (24-12 AWG).

6-7mm wire strip length

Dimensions 77.9 x 35.2 x 32mm
