MEAN WELL LED Driver, 25/70 V Output, 24.5 W Output, 350 mA No
- RS-stocknr.:
- 771-7764
- Artikelnummer Distrelec:
- 301-57-079
- Fabrikantnummer:
- APC-25-350
- Fabrikant:
- MEAN WELL
Bulkkorting beschikbaar
Subtotaal (1 eenheid)*
€ 14,78
(excl. BTW)
€ 17,88
(incl. BTW)
Voeg 6 eenheden toe voor gratis bezorging
Op voorraad
- 62 stuk(s) klaar voor verzending vanaf een andere locatie
- Plus verzending 72 stuk(s) vanaf 03 juli 2026
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Aantal stuks | Per stuk |
|---|---|
| 1 - 4 | € 14,78 |
| 5 - 9 | € 14,06 |
| 10 - 24 | € 13,61 |
| 25 + | € 13,18 |
*prijsindicatie
- RS-stocknr.:
- 771-7764
- Artikelnummer Distrelec:
- 301-57-079
- Fabrikantnummer:
- APC-25-350
- Fabrikant:
- MEAN WELL
Specificaties
Datasheets
Wetgeving en compliance
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | MEAN WELL | |
| Output Voltage | 25/70 V | |
| Product Type | LED Driver | |
| Maximum Output Power | 24.5W | |
| Input Voltage | 127 → 370 V dc, 90 → 264 V ac | |
| Mount Type | Screw | |
| Sub Type | LED Driver | |
| Dimming Operation | No | |
| Input Voltage Type | AC/DC | |
| Terminal Type | Wire | |
| IP Rating | IP30 | |
| Driver Current | 350 mA | |
| Operating Modes | Constant Current | |
| Series | APC-25 | |
| Standards/Approvals | UL, LPS, EAC, CE, BIC | |
| Number of Outputs | 5 | |
| Configuration | Enclosed | |
| Primary Type | AC-DC | |
| Power Dissipation | 24.5W | |
| Alles selecteren | ||
|---|---|---|
Merk MEAN WELL | ||
Output Voltage 25/70 V | ||
Product Type LED Driver | ||
Maximum Output Power 24.5W | ||
Input Voltage 127 → 370 V dc, 90 → 264 V ac | ||
Mount Type Screw | ||
Sub Type LED Driver | ||
Dimming Operation No | ||
Input Voltage Type AC/DC | ||
Terminal Type Wire | ||
IP Rating IP30 | ||
Driver Current 350 mA | ||
Operating Modes Constant Current | ||
Series APC-25 | ||
Standards/Approvals UL, LPS, EAC, CE, BIC | ||
Number of Outputs 5 | ||
Configuration Enclosed | ||
Primary Type AC-DC | ||
Power Dissipation 24.5W | ||
25W Constant current LED Power Supply APC-25 series
The Mean Well APC-25 series, 25W IP30 rated, LED Single output, switching Power Supply. With a universal AC input, short circuit, overload, over voltage protections, withstand 300VAC surge input for 5 seconds. The APC-25 feature an up to date frequency switching topology with 90 to 264VAC input range and up to 84% of high efficiency, the Mean Well APC-25 Power Supply can work between -30 to +70℃ only by using free air convection. The APC-25 series is recommended for use with indoor LED lighting without the need of high level waterproof and dustproof ability.
Universal AC input full range
Constant current mode power supply
Withstand 300VAC Surge input for 5 seconds
Fully isolated Plastic case with 94V-0 fire prevention level
Small and compact size
IP30 design
Pass LPS
Suitable for LED lighting and moving sign applications
84% high efficiency
Cooling by free air convection
Isolation class II, no FG
Class 2 power unit
Protections: Short circuit / Overload / Over voltage
Low cost, high reliability
100% full load burn-in test
2 years warranty
Mean Well LED Drivers, Constant Current
