SMC AN Polyacetal Pneumatic Silencer 10 bar Threaded Metric

RS-stocknr.:: 234-4165
Artikelnummer Distrelec:: 154-23-011
Fabrikantnummer:: AN120-M5
Fabrikant:: SMC

SMC AN Polyacetal Pneumatic Silencer 10 bar Threaded Metric

Bekijk alle Pneumatic Silencers

Subtotaal (1 eenheid)*

€ 2,46

(excl. BTW)

€ 2,98

(incl. BTW)

GRATIS bezorging voor bestellingen van meer dan € 90,00

Op voorraad

255 stuk(s) klaar voor verzending
250 stuk(s) klaar voor verzending vanaf een andere locatie

Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.

Aantal stuks	Per stuk
1 +	€ 2,46

*prijsindicatie

RS-stocknr.:: 234-4165
Artikelnummer Distrelec:: 154-23-011
Fabrikantnummer:: AN120-M5
Fabrikant:: SMC

Specificaties

Datasheets

Wetgeving en compliance

Productomschrijving

Zoek vergelijkbare producten door een of meer kenmerken te selecteren.

Alles selecteren	Attribuut	Waarde
	Merk	SMC
	Connection Size	M5
	Product Type	Pneumatic Silencer
	Material	Polyacetal
	Series	AN
	Connection Type	Threaded
	Thread Standard	Metric
	Noise Reduction	18dB
	Overall Length	15.5mm
	Minimum Operating Temperature	5°C
	Maximum Operating Pressure	10 bar
	Maximum Operating Temperature	+150°C
	Silencer Diameter	M5
	Thread Gender	Male
	Standards/Approvals	RoHS

	Alles selecteren
	Merk SMC
	Connection Size M5
	Product Type Pneumatic Silencer
	Material Polyacetal
	Series AN
	Connection Type Threaded
	Thread Standard Metric
	Noise Reduction 18dB
	Overall Length 15.5mm
	Minimum Operating Temperature 5°C
	Maximum Operating Pressure 10 bar
	Maximum Operating Temperature +150°C
	Silencer Diameter M5
	Thread Gender Male
	Standards/Approvals RoHS

Datasheet - AN120-M5

Land van herkomst:: JP

SMC Series AN Pneumatic Silencer, 18dB Noise Reduction, 10 Bar Maximum Operating Pressure - AN120-M5

This pneumatic silencer reduces exhaust noise and controls airflow from compressed-air systems. It is constructed from polyacetal and is intended for threaded connections in pneumatic equipment, providing a Compact solution where space and noise attenuation are required. The component operates within a defined pressure and temperature range and is suitable for installation where metric threaded fittings are used.

Features and Benefits:

• Reduces noise by 18 dB for quieter exhaust operation
• Withstands up to 10 bar for robust pressure handling
• Operates from 5°C to 150°C for wide thermal conditions
• Male metric thread enables secure connection to ports
• Threaded connection type allows straightforward installation

Applications

• Suitable for pneumatic valves in factory automation systems
• Ideal for use on Air preparation units with metric ports
• Used with pilot-operated devices requiring noise control
• Can be used for inline exhausts on Compact actuators
• Suitable for environments requiring RoHS-compliant components

What material is the component MADE from?

It is manufactured from polyacetal, offering dimensional stability and resistance to common pneumatic environments.

What connection size and gender does it provide?

The unit features a male M5 threaded connection for metric port compatibility.

What are the acceptable operating temperature limits?

The device is rated to operate down to 5°C and up to 150°C.

What thread standard and connection type are used?

A metric thread standard is used and the connection is a threaded type.
