Keysight Technologies RF Switch, SMA Female Connector SP4T, 20 GHz Max, 90 dB Isolation, 15000000 ns, 50Ω Output
- RS-stocknr.:
- 224-0544
- Fabrikantnummer:
- L7204B-161-T24
- Fabrikant:
- Keysight Technologies
Subtotaal (1 eenheid)*
€ 1.627,00
(excl. BTW)
€ 1.968,67
(incl. BTW)
GRATIS bezorging voor bestellingen van meer dan € 90,00
Voorradig bij de fabrikant
- Klaar voor verzending vanaf 07 september 2026
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Aantal stuks | Per stuk |
|---|---|
| 1 + | € 1.627,00 |
*prijsindicatie
- RS-stocknr.:
- 224-0544
- Fabrikantnummer:
- L7204B-161-T24
- Fabrikant:
- Keysight Technologies
Specificaties
Datasheets
Wetgeving en compliance
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | Keysight Technologies | |
| Product Type | RF Switch | |
| Switching Speed | 15000000ns | |
| Port to Port Isolation | 90dB | |
| Contact Configuration | SP4T | |
| Maximum Insertion Loss | 0.3dB | |
| Connector Type | SMA Female | |
| Output Impedance | 50Ω | |
| Height | 66.76mm | |
| Contact Current | 200mA | |
| Contact DC Voltage | 24V dc | |
| Minimum Operating Temperature | -25°C | |
| Length | 57.15mm | |
| Maximum Operating Temperature | 75°C | |
| Standards/Approvals | DEKRA Approval | |
| Series | L | |
| Maximum Frequency | 20GHz | |
| Minimum Frequency | 0Hz | |
| Width | 57.15 mm | |
| Alles selecteren | ||
|---|---|---|
Merk Keysight Technologies | ||
Product Type RF Switch | ||
Switching Speed 15000000ns | ||
Port to Port Isolation 90dB | ||
Contact Configuration SP4T | ||
Maximum Insertion Loss 0.3dB | ||
Connector Type SMA Female | ||
Output Impedance 50Ω | ||
Height 66.76mm | ||
Contact Current 200mA | ||
Contact DC Voltage 24V dc | ||
Minimum Operating Temperature -25°C | ||
Length 57.15mm | ||
Maximum Operating Temperature 75°C | ||
Standards/Approvals DEKRA Approval | ||
Series L | ||
Maximum Frequency 20GHz | ||
Minimum Frequency 0Hz | ||
Width 57.15 mm | ||
- Land van herkomst:
- MY
The Keysight Technologies L7204B unterminated multiport switch improves accuracy in signal RF and microwave signal routing and testing applications. This electromechanical switch provides unmatched isolation and a 0.03 dB insertion loss repeatability, which is warranted for the 2 million cycles of the switch.
Electronic position indicator
Current interrupt capability
Magnetic latching
Note
Manufacturer’s Warranty
