Semikron Danfoss 1200 V 25 A Diode High Voltage 2-Pin DO-203AA SKR 26/12

Bekijk deze categorie
Tijdelijk niet op voorraad
RS-stocknr.:
905-6011
Fabrikantnummer:
SKR 26/12
Fabrikant:
Semikron Danfoss
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren

Merk

Semikron Danfoss

Product Type

Diode

Mount Type

Screw

Package Type

DO-203AA

Maximum Continuous Forward Current If

25A

Peak Reverse Repetitive Voltage Vrrm

1200V

Series

SKR 26

Diode Configuration

Stud Cathode

Rectifier Type

High Voltage

Pin Count

2

Maximum Forward Voltage Vf

1.75V

Minimum Operating Temperature

-40°C

Peak Reverse Current Ir

2mA

Peak Non-Repetitive Forward Surge Current Ifsm

370A

Maximum Operating Temperature

125°C

Length

63mm

Standards/Approvals

No

Height

22mm

Width

32 mm

Automotive Standard

No

Land van herkomst:
BR

Stud Mounting Rectifier Diodes


High current rectifier diodes from Semikron housed in standard stud-mounting cases. Due to the excellent thermal coupling between the device and heatsink stud mounting offers high reliability at high operating currents. With voltage ratings of up to 1700 V these diodes are suitable for most high power rectification applications. Both Stud Anode and Stud Cathode diode configurations are available.

High voltage and current ratings

Robust high-reliability hermetically sealed case

Low thermal resistance between device and heatsink

SKN types have the Anode connected to the stud body

SKR types have the Cathode connected to the stud body

Diodes and Rectifiers, Semikron


Supplied with

Mounting hardware
