NSK 51107 N 1 Row Ball Bearing - 35 mm ID, 52 mm OD
- RS-stocknr.:
- 409-0906
- Fabrikantnummer:
- 51107 N
- Fabrikant:
- NSK
Ontvang bulkkorting
Voeg 5 meer toe om 3% te besparen
Bekijk bulkkortingSubtotaal (1 eenheid)*
€ 20,31
(excl. BTW)
€ 24,58
(incl. BTW)
GRATIS bezorging voor bestellingen van meer dan € 90,00
Op voorraad
- 21 stuk(s) klaar voor verzending vanaf een andere locatie
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Aantal stuks | Per stuk | Bespaar |
|---|---|---|
| 1 - 4 | € 20,31 | - |
| 5 - 9 | € 19,50 | 3% |
| 10 - 24 | € 19,12 | 5% |
| 25 + | € 18,69 | 7% |
*prijsindicatie
- RS-stocknr.:
- 409-0906
- Fabrikantnummer:
- 51107 N
- Fabrikant:
- NSK
Specificaties
Datasheets
Wetgeving en compliance
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | NSK | |
| Inside Diameter | 35mm | |
| Product Type | Ball Bearing | |
| Outside Diameter | 52mm | |
| Race Width | 12mm | |
| Cage Material | Steel | |
| Ball Material | Steel | |
| Number of Rows | 1 | |
| Internal Clearance | CN | |
| Static Load Rating | 48.5kN | |
| Dynamic Load Rating | 22.1kN | |
| Bore Type | Parallel | |
| Series | 1 Extra Light Thrust | |
| Standards/Approvals | No | |
| Limiting Speed | 6000rpm | |
| Bearing Type | Thrust Ball | |
| Race Type | Plain | |
| Alles selecteren | ||
|---|---|---|
Merk NSK | ||
Inside Diameter 35mm | ||
Product Type Ball Bearing | ||
Outside Diameter 52mm | ||
Race Width 12mm | ||
Cage Material Steel | ||
Ball Material Steel | ||
Number of Rows 1 | ||
Internal Clearance CN | ||
Static Load Rating 48.5kN | ||
Dynamic Load Rating 22.1kN | ||
Bore Type Parallel | ||
Series 1 Extra Light Thrust | ||
Standards/Approvals No | ||
Limiting Speed 6000rpm | ||
Bearing Type Thrust Ball | ||
Race Type Plain | ||
Vrijgesteld

Metric Steel Ball Thrust Bearing
NSKs range of thrust bearings are suitable for unidirectional axial loads. Supplied as three-part assemblies, these thrust bearings comprise of two grooved outer raceways and a caged ball set.
These bearings are not suitable for radial loads. Trying to apply and sustain any radial load on a thrust bearing can risk misalignment and damage.
Thrust bearings can be found in a variety of industries such as aerospace, marine and automotive with applications like vertical shaft bearings and steering columns. Commonly found in car gearboxes and clutches, thrust bearings can help to reduce loads as well as help to reduce noise.
