Siemens 3RT2 Overload Relay 3NO, 6.1 A F.L.C, 18 A Contact Rating, 0.4 W, 24 Vdc, 3P, SIRIUS
- RS-stocknr.:
- 124-3067
- Fabrikantnummer:
- 3RT2015-1HB42
- Fabrikant:
- Siemens
2 op voorraad - levertijd is 1 werkdag(en)
Toegevoegd
Prijs Per stuk
€ 50,40
(excl. BTW)
€ 60,98
(incl. BTW)
Aantal stuks | Per stuk |
1 + | € 50,40 |
Better World
Ons Better World assortiment bevat producten die het u gemakkelijk maken om een groenere productkeuze te maken waarop u kunt vertrouwen. Klik hier voor meer informatie.
- RS-stocknr.:
- 124-3067
- Fabrikantnummer:
- 3RT2015-1HB42
- Fabrikant:
- Siemens
Wetgeving en compliance
N.v.t.
- Land van herkomst:
- DE
Productomschrijving
Contactors – 3RT2 Range
The 3RT2 contactors are climate-proof and are suitable and tested for use worldwide, sizes S00 to S2, up to 37 kW
Size S00, up to 7.5 kW
Size S0, up to 18.5 kW
Size S2, up to 37 kW
Screw connection / Spring Clamp
Impulse voltage resistance 6 kV
Insulation voltage 690 V
Real loss power only 4 W
Designation K according to DIN 40719 (extendable to IEC 204-2) & IEC 750; Q according to DIN EN 61346-2
Size S0, up to 18.5 kW
Size S2, up to 37 kW
Screw connection / Spring Clamp
Impulse voltage resistance 6 kV
Insulation voltage 690 V
Real loss power only 4 W
Designation K according to DIN 40719 (extendable to IEC 204-2) & IEC 750; Q according to DIN EN 61346-2
Note
Screw terminals can only be used with screw terminal overloads and spring terminals can only be used with spring terminal overloads.
Approvals
CE, UL, CSA, CCC
Specificaties
Kenmerk | Waarde |
---|---|
FLC Motor Rating | 6.1 A |
Contact Current Rating | 18 A |
Range | SIRIUS |
Pole Configuration | 3P |
Series | 3RT2 |
Mounting Style | DIN Rail Mount |
Power Rating | 0.4 W |
Normal State Configuration | 3NO |
Terminal Type | Screw |
Number Of Auxiliary Contacts | 1 |
Width | 73mm |
Depth | 57.5mm |
Length | 45mm |
Maximum Operating Temperature | +60°C |
Minimum Operating Temperature | -25°C |
Better World Product | Yes |
Operating Temperature Range | -25 → +60 °C |
Better World Claim | Low carbon manufacture |
Contact Voltage Rating | 690 V ac |
Control Voltage | 24 Vdc |
