Schneider Electric, TeSyS LR Thermal Overload Relay 1 NO/1 NC, Trip Dial: 2.5 → 4 A, 4A F.L.C, 5A Contact Rating, 690V
- RS-stocknr.:
- 211-1819
- Fabrikantnummer:
- LRD086
- Fabrikant:
- Schneider Electric
Subtotaal (1 eenheid)*
€ 67,50
(excl. BTW)
€ 81,68
(incl. BTW)
Informatie over voorraden is momenteel niet toegankelijk - Controleer het later nog eens opnieuw
Aantal stuks | Per stuk |
|---|---|
| 1 + | € 67,50 |
*prijsindicatie
- RS-stocknr.:
- 211-1819
- Fabrikantnummer:
- LRD086
- Fabrikant:
- Schneider Electric
Specificaties
Datasheets
Wetgeving en compliance
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | Schneider Electric | |
| Product Type | Thermal Overload Relay | |
| FLC Motor Rating | 4A | |
| Relay Contact Current | 5A | |
| Series | TeSyS LR | |
| Pole and Throw Configuration | 3 | |
| Normal State Configuration | 1 NO/1 NC | |
| Reset Method | Push Button | |
| IP Rating | IP20 | |
| Width | 45mm | |
| Adjustable Current Range | 2.5 → 4 A | |
| Number of Auxiliary Contacts | 2 | |
| Minimum Operating Temperature | -20°C | |
| Length | 66mm | |
| Maximum Operating Temperature | 60°C | |
| Contact Voltage | 690V | |
| Depth | 70mm | |
| Standards/Approvals | EN 60947-4-1, UL 508, ATEX D 94/9/CE, IEC 60947-4-1, EN 60947-5-1, CSA C22.2 No 14, IEC 60947-5-1 | |
| Control Voltage | 690V ac | |
| Alles selecteren | ||
|---|---|---|
Merk Schneider Electric | ||
Product Type Thermal Overload Relay | ||
FLC Motor Rating 4A | ||
Relay Contact Current 5A | ||
Series TeSyS LR | ||
Pole and Throw Configuration 3 | ||
Normal State Configuration 1 NO/1 NC | ||
Reset Method Push Button | ||
IP Rating IP20 | ||
Width 45mm | ||
Adjustable Current Range 2.5 → 4 A | ||
Number of Auxiliary Contacts 2 | ||
Minimum Operating Temperature -20°C | ||
Length 66mm | ||
Maximum Operating Temperature 60°C | ||
Contact Voltage 690V | ||
Depth 70mm | ||
Standards/Approvals EN 60947-4-1, UL 508, ATEX D 94/9/CE, IEC 60947-4-1, EN 60947-5-1, CSA C22.2 No 14, IEC 60947-5-1 | ||
Control Voltage 690V ac | ||
- Land van herkomst:
- FR
The Schneider Electric TeSys Series is best suited for applications involving Motor Control and Starting of Motor. The Schneider Electric series is known for providing a better compatibility which makes it The Schneider Electric best choice for this application.
Easy maintenance checks, check The Schnieder Electric's tightening of cables through conducting thermographic testing and checking The Schnieder Electric's mechanical operation of The Schnieder Electric's product through manually operating The Schnieder E
