Schurter IP65 SPST-NO Red Membrane Keyboard Switch, 125mA, 60 °C, -25 °C
- RS-stocknr.:
- 270-7931
- Fabrikantnummer:
- 1241.1104.7093
- Fabrikant:
- Schurter
Subtotaal (1 eenheid)*
€ 10,25
(excl. BTW)
€ 12,40
(incl. BTW)
GRATIS bezorging voor bestellingen van meer dan € 90,00
Op voorraad
- 67 stuk(s) klaar voor verzending vanaf een andere locatie
- Plus verzending 200 stuk(s) vanaf 07 oktober 2026
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Aantal stuks | Per stuk |
|---|---|
| 1 + | € 10,25 |
*prijsindicatie
- RS-stocknr.:
- 270-7931
- Fabrikantnummer:
- 1241.1104.7093
- Fabrikant:
- Schurter
Specificaties
Datasheets
Wetgeving en compliance
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | Schurter | |
| Product Type | Membrane Keyboard Switch | |
| Contact Configuration | SPST-NO | |
| Switch Contact Current | 125mA | |
| Operating Force | 3N | |
| Switch Operation | Momentary | |
| Mechanical Life Per Key | 1000000Operations | |
| Contact Resistance | 50mΩ | |
| IP Rating | IP65 | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 60°C | |
| Contact DC Voltage | 48V dc | |
| Actuator Colour | Red | |
| Contact Material | Silver | |
| Standards/Approvals | REACH, RoHS, CHINA RoHS, IEC/UL 62368-1 | |
| Series | MCS 18 | |
| Alles selecteren | ||
|---|---|---|
Merk Schurter | ||
Product Type Membrane Keyboard Switch | ||
Contact Configuration SPST-NO | ||
Switch Contact Current 125mA | ||
Operating Force 3N | ||
Switch Operation Momentary | ||
Mechanical Life Per Key 1000000Operations | ||
Contact Resistance 50mΩ | ||
IP Rating IP65 | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 60°C | ||
Contact DC Voltage 48V dc | ||
Actuator Colour Red | ||
Contact Material Silver | ||
Standards/Approvals REACH, RoHS, CHINA RoHS, IEC/UL 62368-1 | ||
Series MCS 18 | ||
- Land van herkomst:
- CZ
The Schurter Momentary action switch available in version square or round pattern with different colors. This switch has high lifetime with 5 million actuations. This switch supports front and rear tested to degree of protection IP65 with snap in type from front side. This switches has solder terminals with tin plated soldering aid.
Unique mechanical switches with tactile feedback
Small mounting depth
Various lettering options
Duration of Bounce is typically 1 msec
