Aten 4 Port USB DVI KVM Switch 3.5 mm Stereo 1920 x 1200 pixel Maximum Resolution
- RS-stocknr.:
- 144-9072
- Artikelnummer Distrelec:
- 125-49-622
- Fabrikantnummer:
- CS1764A
- Fabrikant:
- Aten
Subtotaal (1 eenheid)*
€ 369,92
(excl. BTW)
€ 447,60
(incl. BTW)
GRATIS bezorging voor bestellingen van meer dan € 90,00
Op voorraad
- Plus verzending 7 stuk(s) vanaf 27 april 2026
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Aantal stuks | Per stuk |
|---|---|
| 1 + | € 369,92 |
*prijsindicatie
- RS-stocknr.:
- 144-9072
- Artikelnummer Distrelec:
- 125-49-622
- Fabrikantnummer:
- CS1764A
- Fabrikant:
- Aten
Specificaties
Datasheets
Wetgeving en compliance
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | Aten | |
| Video Connection Type | DVI | |
| Product Type | KVM Switch | |
| Number of Ports | 4 | |
| Number of Video Outputs | 5 | |
| Maximum Resolution | 1920 x 1200 pixel | |
| Keyboard/Mouse Connection Type | USB | |
| Audio Connection Type | 3.5 mm Stereo | |
| Standards/Approvals | HDCP, RoHS, DVI specifications, USB 2.0 | |
| Depth | 88mm | |
| Width | 88mm | |
| Height | 55.5mm | |
| Alles selecteren | ||
|---|---|---|
Merk Aten | ||
Video Connection Type DVI | ||
Product Type KVM Switch | ||
Number of Ports 4 | ||
Number of Video Outputs 5 | ||
Maximum Resolution 1920 x 1200 pixel | ||
Keyboard/Mouse Connection Type USB | ||
Audio Connection Type 3.5 mm Stereo | ||
Standards/Approvals HDCP, RoHS, DVI specifications, USB 2.0 | ||
Depth 88mm | ||
Width 88mm | ||
Height 55.5mm | ||
- Land van herkomst:
- CN
4-Port USB DVI/Audio KVMP Switch
The CubiQ CS1764A USB 2.0 DVI KVMP Switch combines a 4-port KVM switch with a 2-port USB 2.0 hub at the same time as it provides an interface for a digital monitor (DVI). The CS1764A comes with Aten Video DynaSync technology, which optimises display resolution, and power on detection. When one computer is powered off, the CS1764A automatically switches to the next powered-on computer
• One USB console controls four DVI computers and two extra USB 2.0 devices
• 2-port USB 2.0 hub built in
• Fully compliant with the USB 2.0 specification
• Computer selection via front panel push buttons and hotkeys
• Audio enabled
• Multiplatform support - Windows, Linux, Mac and Sun
• Independent switching of KVM, USB, and Audio focus
• DVI digital and analogue monitor support
• HDCP compliant
• Video DynaSync
• Power on detection
• Auto Scan Mode for monitoring all computers
• Firmware upgradable via USB
KVM Switches - ATEN
Supplied with
1x CS1764A USB 2.0 DVI KVMP Switch
4x KVM Cable (DVI-D, USB, Audio; 1.8m)
1x Power Adapter
1x User Instructions
4x KVM Cable (DVI-D, USB, Audio; 1.8m)
1x Power Adapter
1x User Instructions
