Bartec Plunger Limit Switch, 1 NO/1 NC, IP66, Plastic Housing, 400 V ac, 2 A
- RS-stocknr.:
- 742-833
- Fabrikantnummer:
- 07-2911-1530/30
- Fabrikant:
- Bartec
Subtotaal (1 eenheid)*
€ 464,97
(excl. BTW)
€ 562,61
(incl. BTW)
GRATIS bezorging voor bestellingen van meer dan € 75,00
Op voorraad
- 5 stuk(s) klaar voor verzending
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Aantal stuks | Per stuk |
|---|---|
| 1 + | € 464,97 |
*prijsindicatie
- RS-stocknr.:
- 742-833
- Fabrikantnummer:
- 07-2911-1530/30
- Fabrikant:
- Bartec
Specificaties
Datasheets
Wetgeving en compliance
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | Bartec | |
| Product Type | Limit Switch | |
| Actuator Type | Plunger | |
| IP Rating | IP66 | |
| Contact Configuration | 1 NO/1 NC | |
| Housing Material | Plastic | |
| Contact Type | Snap Action | |
| Switching Current | 2 A | |
| Switching DC Voltage | 250 V dc | |
| Minimum Operating Temperature | -20°C | |
| Switching AC Voltage | 400 V ac | |
| Maximum Operating Temperature | 40°C | |
| Depth | 15.8mm | |
| Standards/Approvals | RoHS, EN, IEC | |
| Width | 25.5 mm | |
| Length | 46.2mm | |
| Hazardous Area Certification | ATEX | |
| Mechanical Life | 2000000Cycles | |
| Alles selecteren | ||
|---|---|---|
Merk Bartec | ||
Product Type Limit Switch | ||
Actuator Type Plunger | ||
IP Rating IP66 | ||
Contact Configuration 1 NO/1 NC | ||
Housing Material Plastic | ||
Contact Type Snap Action | ||
Switching Current 2 A | ||
Switching DC Voltage 250 V dc | ||
Minimum Operating Temperature -20°C | ||
Switching AC Voltage 400 V ac | ||
Maximum Operating Temperature 40°C | ||
Depth 15.8mm | ||
Standards/Approvals RoHS, EN, IEC | ||
Width 25.5 mm | ||
Length 46.2mm | ||
Hazardous Area Certification ATEX | ||
Mechanical Life 2000000Cycles | ||
- Land van herkomst:
- DE
EExd-DIN limit switch
The dimensions, mounting dimensions and actuating elements of the EExd limit switch comply with DIN 50041. Versions with aluminium housing. The switch has a changeover contact implemented as a snap-action contact.
An explosion-proof microswitch is used as the switching element. Two actuator knobs are available, each of which can be rotated by 90° by loosening 4 screws, so that up to 4 actuation directions are possible. The connection lead (HO5VV-F 0.75 mm2) is 5 m long and allows easy connection to a junction box or polyester distributor.
Group and Category
PTB no. 79 / 1016X
Certificate No.
II G EEx d IIC T6
