Texas Instruments, 4 2-Input AND Schmitt Trigger Input Logic Gate, 14-Pin SOIC

RS-stocknr.:: 267-7437
Fabrikantnummer:: CD74HCT21M96
Fabrikant:: Texas Instruments

Texas Instruments, 4 2-Input AND Schmitt Trigger Input Logic Gate, 14-Pin SOIC

Momenteel niet beschikbaar

We weten niet of dit item nog op voorraad komt, RS is van plan dit binnenkort uit ons assortiment te halen.

RS-stocknr.:: 267-7437
Fabrikantnummer:: CD74HCT21M96
Fabrikant:: Texas Instruments

Specificaties

Wetgeving en compliance

Zoek vergelijkbare producten door een of meer kenmerken te selecteren.

Alles selecteren	Attribuut	Waarde
	Merk	Texas Instruments
	Logic Function	AND
	Product Type	Logic Gate
	Mount Type	Surface
	Number of Elements	4
	Number of Inputs per Gate	2
	Schmitt Trigger Input	Yes
	Package Type	SOIC
	Pin Count	14
	Logic Family	CMOS
	Input Type	LS-TTL
	Maximum Propagation Delay Time @ CL	41ns
	Minimum Operating Temperature	-55°C
	Maximum Operating Temperature	125°C
	Standards/Approvals	REACH, RoHS
	Length	8.7mm
	Minimum Supply Voltage	4.5V
	Series	CD74HCT21
	Maximum Supply Voltage	5.5V
	Automotive Standard	No

	Alles selecteren
	Merk Texas Instruments
	Logic Function AND
	Product Type Logic Gate
	Mount Type Surface
	Number of Elements 4
	Number of Inputs per Gate 2
	Schmitt Trigger Input Yes
	Package Type SOIC
	Pin Count 14
	Logic Family CMOS
	Input Type LS-TTL
	Maximum Propagation Delay Time @ CL 41ns
	Minimum Operating Temperature -55°C
	Maximum Operating Temperature 125°C
	Standards/Approvals REACH, RoHS
	Length 8.7mm
	Minimum Supply Voltage 4.5V
	Series CD74HCT21
	Maximum Supply Voltage 5.5V
	Automotive Standard No

Texas Instruments, 4 2-Input AND Schmitt Trigger Input Logic Gate, 14-Pin SOIC
